LPP
Peripheral Pump
Application
It can be used to transfer clean water or other liquids similar to water in physical and chemical properties.It is suitable for industrial use and urban water supply, pressure boosting for high buildings and fire fighting, garden irrigation, long-distance water transfer, heating ventilation and air controlling, circulation and pressure boosting for cold and hot water or supporting equipment, etc.
Pump
Cast iron pump body and support under special anti-rust treatmentBrass impeller (stainless or plastic)
AISI 304 shaft
Max.liquid temperature: +60℃
Max.suction: +8m
C&U bearing
Motor with cooper winding
Built-in thermal protected for single phase motor
Insulation class: F
Protection class: IPX4
Max. ambient temperature: +40℃
| MODEL | POWER | Inlet/Outlet |
MAX. FLOW (L/min) |
MAX.HEAD (m) |
MAX.SUCT (m) |
G.W (kg) |
QUANTITY (PCS/TEU) |
||
| KW | HP | A | |||||||
| LPP-130A | 1 | 1.3 | 6.5 | 1½" , 1½" | 220 | 18 | 8 | 19 | 1300 |
| LPP-200A | 1.5 | 2 | 9.5 | 2" , 2" | 350 | 20 | 8 | 20.5 | 1000 |
| LPP-150B | 1.1 | 1.5 | 7.2 | 1" , 1" | 400 | 16 | 8 | 18.5 | 1100 |
| LPP-200B | 1.5 | 2 | 9.5 | 1" , 1" | 450 | 20 | 8 | 20 | 1100 |
| LPP-150C | 1.1 | 1.5 | 8.0 | 1¼" , 1" | 130 | 48.5 | 8 | 24 | 830 |
| LPP-200C | 1.5 | 2 | 10 | 1¼" , 1" | 142 | 55 | 8 | 26 | 770 |
