Vm1500F Vm2200F
Application
Max.Depth:5mMax.fluid temperature:40℃
Liquid PH value:4-10
Liquid kinematic viscosity: 7×10-7--23×10-6 m2/s
Max.liquid density: 1.2×103 kg/m3
Operating conditions
Waste water drainage in factories, construction and commercial facilitiesDrainage system in municipal sewage treatment plants
Drainage station in residential quarters
Municipal projects
Methane pools and field irrigation in countryside
Component
Pump body: Cast iron
Motor housing: AISI304 SS
Impeller: Cast iron
Motor shaft: Carbon steel
Mechanical seal: Ceramic-Graphite
Cable length: 6m
| Model |
Power (kw) |
Outlet Diameter (mm) |
Voltage/Frequency (V/Hz) |
Max.Flow (L/min) |
Max.Head (m) |
Max.Diameter of Particle (mm) |
G.W. (kg) |
Dimension (cm) |
| Vm1500FX | 1.5 | 75 | 230/50 | 700 | 12 | 25 | 32.5 | 28*27*62 |
| Vm1500FD | 1.5 | 75 | 230/50 | 666 | 17 | 25 | 34.5 | 28*27*62 |
| Vm2200FX | 2.2 | 75 | 230/50 | 800 | 17 | 30 | 37 | 28*27*62 |
| Vm2200FD | 2.2 | 75 | 230/50 | 816 | 19 | 30 | 37.5 | 28*27*62 |
